Cable Carriers for Linear Motion

Categories
Filter
Application Requirements
System
Dimension
Crossbar style
Unsupported length and fill weight
Speed and acceleration
Parameters

Number of products: 19

E2 micro Series 045 energy chain, not to open

  • Inner height hi: 10,3mm
  • Inner width Bi: 6 - 64mm
  • Bend radii R: 18 - 83mm
  • Pitch: 13mm
  • Design: Non snap-open
from 8.46 USD/ft
18 variants ready for shipping:
18 variants within 24 hours
Shop now

E2 micro Series E2.10 energy chain, openable along the outer radius

  • Inner height hi: 10,1mm
  • Inner width Bi: 6 - 50mm
  • Bend radii R: 18 - 38mm
  • Pitch: 20mm
  • Design: Openable along the outer radius
from 10.43 USD/ft
21 variants ready for shipping:
9 variants within 24 hours
Shop now

E2 micro Series 03 energy chain, not to open

  • Inner height hi: 5mm
  • Inner width Bi: 5 - 10mm
  • Bend radii R: 10 - 28mm
  • Pitch: 10mm
  • Design: Non snap-open
from 8.19 USD/ft
15 variants ready for shipping:
14 variants within 24 hours
1 variants within 12 working days
Shop now

E2 micro Series 04 energy chain, not to open

  • Inner height hi: 7mm
  • Inner width Bi: 7 - 30mm
  • Bend radii R: 15 - 48mm
  • Pitch: 16,7mm
  • Design: Non snap-open
from 8.17 USD/ft
25 variants ready for shipping:
24 variants within 24 hours
1 variants within 12 working days
Shop now

E2 micro Series 05 energy chain, not to open

  • Inner height hi: 10mm
  • Inner width Bi: 6 - 64mm
  • Bend radii R: 18 - 38mm
  • Pitch: 20mm
  • Design: Non snap-open
from 8.17 USD/ft
18 variants ready for shipping:
15 variants within 24 hours
3 variants within 12 working days
Shop now

E2 micro Series 06 energy chain, not to open

  • Inner height hi: 10,5mm
  • Inner width Bi: 6 - 64mm
  • Bend radii R: 18 - 38mm
  • Pitch: 20mm
  • Design: Non snap-open
from 8.46 USD/ft
24 variants ready for shipping:
22 variants within 24 hours
2 variants within 12 working days
Shop now

E2 micro Series 08 energy chain, not to open

  • Inner height hi: 14,9mm
  • Inner width Bi: 10 - 50mm
  • Bend radii R: 25 - 48mm
  • Pitch: 20mm
  • Design: Non snap-open
from 9.41 USD/ft
21 variants ready for shipping:
14 variants within 24 hours
5 variants within 12 working days
Shop now

E2 micro Series B07 energy chain, openable along the outer radius

  • Inner height hi: 10,3mm
  • Inner width Bi: 16 - 40mm
  • Bend radii R: 18 - 38mm
  • Pitch: 20mm
  • Design: Openable along the outer radius
from 11.38 USD/ft
12 variants ready for shipping:
12 variants within 24 hours
Shop now

E2 micro Series B09 energy chain, openable along the outer radius

  • Inner height hi: 14,3mm
  • Inner width Bi: 16 - 40mm
  • Bend radii R: 28 - 48mm
  • Pitch: 20mm
  • Design: Openable along the outer radius
from 13.65 USD/ft
12 variants ready for shipping:
12 variants within 24 hours
Shop now

E2 micro Series 074 energy chain, openable along the inner radius

  • Inner height hi: 11,5mm
  • Inner width Bi: 10 - 20mm
  • Bend radii R: 18 - 38mm
  • Pitch: 20mm
  • Design: Openable along the inner radius
Upon request
Shop now

E2 micro Series 094 energy chain, openable along the inner radius

  • Inner height hi: 14,3mm
  • Inner width Bi: 16 - 40mm
  • Bend radii R: 28 - 48mm
  • Pitch: 20mm
  • Design: Openable along the inner radius
Upon request
Shop now

E2 micro Series E2i.10 energy chain, openable along the inner radius

  • Inner height hi: 10,1mm
  • Inner width Bi: 6 - 50mm
  • Bend radii R: 18 - 38mm
  • Pitch: 20mm
  • Design: Openable from both sides along the inner radius
from 10.63 USD/ft
21 variants ready for shipping:
9 variants within 24 hours
Shop now

E2 micro Series E2C.10 energy chain, enclosed

  • Inner height hi: 10mm
  • Inner width Bi: 6 - 50mm
  • Bend radii R: 18 - 38mm
  • Pitch: 20mm
  • Design: Non snap-open
from 8.46 USD/ft
21 variants ready for shipping:
9 variants within 24 hours
Shop now

E2 micro Series E2.15 energy chain, openable along the outer radius

  • Inner height hi: 14,4mm
  • Inner width Bi: 10 - 50mm
  • Bend radii R: 28 - 48mm
  • Pitch: 20mm
  • Design: Openable along the outer radius
from 11.61 USD/ft
21 variants ready for shipping:
21 variants within 24 hours
Shop now

E2 micro Series E2i.15 energy chain, openable along the inner radius

  • Inner height hi: 14,4mm
  • Inner width Bi: 10 - 50mm
  • Bend radii R: 28 - 48mm
  • Pitch: 20mm
  • Design: Openable from both sides along the inner radius
from 10.81 USD/ft
21 variants ready for shipping:
21 variants within 24 hours
Shop now
