Apiro® modular robotic gearbox system

Apiro® modular robotic gearbox configurator

Apiro® modular robotic gearbox configurator

With the configurator, design workspaces for single and multiple DoF variations by your application requirements. Download CAD files, get a quote or add to cart to purchase.
List
Tile

Number of products: 41

New

Apiro® bevel gear
Apiro® bevel gear
  • 1:1 transmission ratio
  • Splash-proof
  • Ini-kit available for all variants
from 171.62 USD/Pc.
2 items, ready for shipping:
2 within 30 working days
Shop now
New

Apiro® gear with double cantilever axis
Apiro® gear with double cantilever axis
  • The cantilever axis from the Apiro® modular transmission system is now available with a double cantilever axis
  • Suitable for motorized or manual drive
  • The modules can be used in series or parallel for strokes from 60 - 1,050 mm
from 165.23 USD/Pc.
22 items, ready for shipping:
22 within 30 working days
Shop now

drygear® Apiro | Gearbox with hollow shaft
drygear® Apiro | Gearbox with hollow shaft
The standard version among Apiro gearboxes: the worm gear with hollow shaft enables flexible drive connections.

Product information
  • available transmissions 4:1, 32:1, 64:1
  • Output torque 2.5Nm
Optionally available
  • more transmissions
  • various fasteners
from 166.51 USD/Pc.
3 items, ready for shipping:
3 within 30 working days
Shop now

drygear® Apiro | Gearbox with multi-functional profile
drygear® Apiro | Gearbox with multi-functional profile
The gearbox and the direct multi-function profile can be used, among other things, to implement series connections of gearboxes.

Product information
  • available transmissions 4:1, 32:1, 64:1
  • Output torque 2.5Nm
Optionally available
  • more transmissions
  • various fasteners
from 170.21 USD/Pc.
3 items, ready for shipping:
3 within 30 working days
Shop now

drygear® Apiro | Gearbox with rotary disc
drygear® Apiro | Gearbox with rotary disc
This gearbox from the Apiro modular gearbox system is particularly suitable for slewing ring applications, as it can, among other things, be used as an external rotary axis.

Product information
  • available transmissions 4:1, 32:1, 64:1
  • Output torque 2.5Nm
Optionally available
  • more transmissions
  • various fasteners
from 202.07 USD/Pc.
3 items, ready for shipping:
1 in 2 working days
2 within 30 working days
Shop now

drygear® Apiro | Gearbox with coupling
drygear® Apiro | Gearbox with coupling
The version with couplings on the output allows the attachment of various shafts with a maximum diameter of 12 millimetres.

Product information
  • available transmissions 4:1, 32:1, 64:1
  • Coupling diameter 8mm
Optionally available
  • more transmissions
  • various fasteners
from 193.17 USD/Pc.
3 items, ready for shipping:
3 within 30 working days
Shop now

drygear® Apiro | Gearbox with manual clamp and position indicator
drygear® Apiro | Gearbox with manual clamp and position indicator
The complete Apiro gear unit including manual clamp and position indicator is ideal for manual adjustments and fixings.

Product information
  • available transmissions 4:1, 32:1, 64:1
  • Accessories can be pivoted in four positions:0°, 90°, 180°, 270°
Optionally available
  • more transmissions
  • various fasteners
from 299.82 USD/Pc.
3 items, ready for shipping:
3 within 30 working days
Shop now

drygear® Apiro cantilever axis
drygear® Apiro cantilever axis
The linear gearbox enables different strokes in the application and contains rack and pinion elements. It can be configured in different lengths, for example, for pusher applications.
  • Motor drive or manual drive
  • Modules can be connected in series or in parallel
  • INI kit available for all options
  • Application temperature: +5°C to +50°C
from 107.75 USD/Pc.
22 items, ready for shipping:
22 within 30 working days
Shop now

drygear® Apiro | Planetary gearbox with cantilever axis
drygear® Apiro | Planetary gearbox with cantilever axis
The modular Apiro cantilever axis is also available with an integrated planetary gearbox.

Product information
  • available transmission ratio 4:1
  • very compact
Optionally available
  • various fasteners
from 199.44 USD/Pc.
22 items, ready for shipping:
22 within 30 working days
Shop now

drygear® Apiro | Gearbox with output coupling
drygear® Apiro | Gearbox with output coupling
The standard version among Apiro gearboxes: the worm gear with drive coupling enables a direct connection. The gearbox with an output shaft enables a direct connection to the output and is ideally suited for connection to drylin drive technology.

Product information
  • available transmissions 4:1, 32:1, 64:1
  • Output shaft diameter: 8mm
Optionally available
  • more transmissions
  • various fasteners
from 206.84 USD/Pc.
4 items, ready for shipping:
4 within 30 working days
Shop now

drygear® Apiro connection to drylin SLW, SHT
drygear® Apiro connection to drylin SLW, SHT
Direct connection at the output to drylin SLW, SHT unit
Available options are:
  • SLW-1660
  • SHT-12 / SLW-10xx
  • SHT-20
  • SHT-30/SLW-1660
  • SHT-BB-20 / SLW-BB-2080
  • SHT-BB-30 / SLW-BB-25120
For the Apiro-drylin connection, the matching Apiro gearbox is also required!
from 87.33 USD/Pc.
6 items, ready for shipping:
6 within 30 working days
Shop now

drygear® Apiro | Connection to dryspin® lead screws
drygear® Apiro | Connection to dryspin® lead screws
A simple and direct connection of the Apiro gearboxes to the dryspin lead screws

Product information
  • available transmissions 4:1, 32:1, 64:1
  • Available options: DS10x25, DS12x5 and TR16x2
Optionally available
  • more transmissions
  • various fasteners
from 196.44 USD/Pc.
9 items, ready for shipping:
9 within 30 working days
Shop now
New

Apiro® Robotic kit
Apiro® Robotic kit
The Apiro® (Greek for "infinite") robot gearbox construction kit is now available as a starter kit. Build your own robot, including instructions.

The following assemblies can be built:
1. Apiro® room gantry
2. Apiro® area gantry
3. Apiro® mini articulated arm robot
4. Apiro® pusher
5. Apiro® 2-axis picker
6. Apiro® 3-axis picker
7. Apiro® 360° picker
8. Apiro® SCARA
Upon request
Shop now

drygear® Apiro motor kit Nema 17 with strand
drygear® Apiro motor kit Nema 17 with strand
  • Installation size: NEMA17/flange installation size 42mm
  • Holding torque: 0.5Nm
  • Nominal current: 1.80A
  • Motor connection:  stranded wire
  • Price without gearbox
from 166.91 USD/Pc.
1 items, ready for shipping:
1 within 30 working days
Shop now

drygear® Apiro motor kit Nema 17 with connector and encoder
drygear® Apiro motor kit Nema 17 with connector and encoder
  • Installation size: NEMA17/flange installation size 42mm
  • Holding torque: 0.50Nm
  • Nominal current: 1.80A
  • Motor connection: metric connector
  • Price without gearbox
from 429.35 USD/Pc.
1 items, ready for shipping:
1 within 30 working days
Shop now
