Breakage detection (EC.B) for e-chains®

Unfortunate circumstances – not always a chain failure

Links in e-chains® are made for tough continuous use. If, nevertheless, forces should somehow overtax your e-chain®, the EC.B sensor detects link breakage in your e-chain® immediately and, should the worst happen, sends a notification right away. This allows you or your system to intervene, frequently preventing both additional damage (to the opposite chain link) and system shutdown. If you believe that this kind of security is exactly right for your application, you can assemble the suitable package with our selection aid. Installation details can be found here.

Discover EC.B functionality in 82 seconds

  • Module (EC = e-chain B = break detection) detects breaks in individual chain links
  • A rope is passed through the e-chain and tightened to record any change in length and report it to the EC.B. sensor.
  • This detects chain breaks, shuts down the system and prevents further damage
  • All the information is stored on an SD card for analysis.

EC.B application examples

  • Gliding applications
  • Great material load due to heat
  • Dust and dirt

Contact an expert now
Smart plastics sensors

Mounting instructions for i.Sense EC.B

Mounting instructions for i.Sense EC.B

Assembly Overview:

  • Simple clear diagrams on 16 pages.
  • 13 steps for the correct installation of the EC.B module
  • Includes other required materials and tools.

Download installation instructions

How does EC.B work?


Video contents

  • What is breakage detection EC.B in an energy chain?
  • Why is EC.B breakage detection used at all?
  • How is the EC.B system designed?
  • What is the use of the EC.B system?

EC.B mounted on a container crane

  • The EC.B (EC = e-chain®, B = break detection) module is installed on the moving end of the e-chain®
  • Special mounting brackets allow the EC.B. sensor to be mounted on the moving end of the e-chain®
  • Supplementing break detection (EC.B) with an EC.M (EC = e-chain®, M = motion) sensor moves the system from mere condition monitoring to  predictive maintenance. The additional measured values (speed, acceleration and temperature) allow the system to calculate service life and display maintenance times.

Learn more about smart solutions in the crane industry

Explore smart plastics industry 4.0 tools and solutions

Smart CAD

Smart Plastics CAD

Design smart e-chain® systems faster.

Our intelligent e-chain® systems are already reliably in use in hundreds of thousands of applications worldwide - from beverage machines and CNC machines to steel mills. Unsupported lengths can be bridged without problems and long travels are conceivable for the most varied of industries.

Smart Configurator

product selector

Choose a custom smart plastics solution

With just a little information about your application, the online consultant guides you in a targeted manner to a pre-selection of smart plastics solutions. During the selection process, the tool provides an overview of the current smart plastics options.

Learn More

Smart Applications

Smart applications

Customer application examples with smart plastics

Whether a new project for Industry 4.0 or efficiency-driven retrofitting - our smart plastics solutions are available as universal modular systems and can be individually adapted to any system.



Learn More
