iglide® J4 - low cost and low wear

  • iglide® J4 is the new low-cost material for long lifetimes for low to medium loads.
  • Self-lubricating, maintenance free
  • Low-cost-material for large volumes
  • Low coefficients of friction
  • Media resistant
  • Lowest humidity absorption
material data: iglide® J4
Density1,48 g/cm3
ColorGray
Max. moisture absorption at 73°F and 50% r.h.:0,3 weight-%
Max. water absorption1,3 weight-%
Upper long-term application temperature194°F
Upper short-term application temperature248°F
Lower application temperature-58°F
Bending E-module2.350 MPa
Max. surface pressure35 MPa
Surface resistance>1012Ω
