Move loads easier - hybrid bearings with two rollers

WJRMT

New hybrid roller bearing with double roller
Smooth adjustment and very robust in function: these are drylin® W hybrid roller bearings. The new tandem roller bearing accommodates higher loads. The integrated pendulum mounting ensures that the rollers absorb the load evenly. The tandem roller bearings are available in installation sizes ø10 and 20mm, suitable for the drylin® linear rails WS-10 and WS-20.

Make an enquiry about this product
Icon arrow

Tech up

  • Two times higher load capacity (compared to the standard version)
  • Uniform load distribution thanks to the swivel bearing system
  • Up to 50% lighter than using two individual bearings
  • Ready-to-fit tandem bearings suitable for drylin® W rail profiles WS-10 and WS-20
Icon money

Cost down

  • Fast assembly: one component instead of two
  • No alignment: tandem design instead of two single bearings
  • Flexible: two installation positions possible
icon people

Proof

  • Tested: weight of 2 single bearings 464g, tandem bearing 215g, 54% savings
  • Up to four times quieter than metal bearings in operation
icon sustainability

Sustainability

  • 100% lubrication-free operation
  • No contamination in the application environment
  • Maintenance-free due to self-lubricating high-performance polymers from igus®

Ask our experts

Contact igus expert

Our igus® expert will gladly advise you in this regard with no strings attached.

Contact us here

Download current catalogue

News HMI 2020

Easily download the PDF with a mouse click and learn about igus® innovations.

Go to the PDF downloads

Further drylin® products

shopping icon

Discover a variety of products and solutions for your problems in our online shop.

Go to the other products

Order a free sample and test WJRMT

WJRMT

Order a WJRMT sample and test for yourself. Of course completely free of charge.

Order sample here

Application examples of our drylin® products

Carpentry project Cologne Chamber of Trade

igus® helps prospective carpenters with their project

As part of a course in machinery at the Cologne Chamber of Trade, prospective carpenters combined Scandinavian looks with industrial design. The results of this project are a pull-out bedside table and a coffee table with rotating drawer and pull-out opening. The pieces of furniture are not only beautiful to look at, but have a certain quality.

igus blister centre

igus® in the storage technology of a blister centre

igus® bearing technology in an automated blister centre. Automated medicine handling for chemist shops/pharmacies: with over 7,500 systems installed worldwide, Rowa Systems from Becton Dickinson is a clear leader in this market segment.

igus labelling machine

igus® components in KHS labelling machines

Numerous rotary and linear bearings from the igus® product range are not the only ones installed in KHS GmbH's labelling machines. igus® also supplies complete, ready-to-install modules such as adjustment systems and guide rollers, etc.

fabmaker educational printer

Linear guide components for 3D printers

Technology-oriented startup businesses are more daring than others in deploying emerging technologies in new, marketable products. This is also true of fabmaker GmbH, Braunschweig, which has developed a 3D printer for educational purposes.
