e-skin® cleanroom e-chain® cable carriers


The e-skin is a hose consisting of an upper and lower shell that form a sealed tube when connected to each other. It consists of igumid SK, a polymer material developed specifically for this. The simple and reclosable opening mechanism enables easy maintenance and inspection of the installed cables. Operating temperature +10°C / +50°C.  Applications include:  Fast, short, unsupported applications, standing and hanging applications, pick & place applications, printers, medical technology and all machines where corrugated tubes are used, display and semiconductor production.

e-skin

Technical Details:

1)  Mounting brackets: strong, with integrated strain relief
2)  Small installation space: small bend radii
3)  Unsupported application due to stop-dogs on the upper shell of the e-skin


4) Cleanroom ISO Class 1: virtually no wear or abrasion
5) Cable-friendly: defined minimum bend radius
6) Easy to assemble: Upper and lower shells can be opened for easy filling


Shop e-skin series SK28:

Part No. Bi Ba hi ha R min.
More about selected part:
myCatalog myCatalog
e-skin drawing Drawing e-skin SK28
A= moving end
B= fixed end

Shop Mounting bracket series SK28:

Part No.ABCDEFG
SK280.068.12.1
Full set without tiewrap plates
104926835462118 Request
SK280.068.12ZB.1
Full set incl. tiewrap plates
104926835462118

 Request

e-skin mounting bracket
e-skin SK28 mounting bracket drawing

Shop Interior separation:

The interior separation system for the igus® e-skin consists of individual separators and shelves, which can be inserted in the e-skin in a variety of ways and attached to the ridges.




Part No.

SK28.1.01 - Separator, slotted - unassembled Request
SK28.1.1.01 - Separator, slotted - assembled Request
110.63.1 - Full-width shelf - unassembled Request
111.63.1 - Full-width shelf - assembled Request



Separator for the e-skin

Shop e-skin series SK40

Part No. Bi Ba hi ha R min.
More about selected part:
myCatalog myCatalog
SK40 Drawing

Shop mounting bracket series SK40

Part No.ABCDEFG
SK400.085.12.1
Full set without tiewrap plates
1251136835664118 Request
SK400.085.12ZB.1
Full set incl. tiewrap plates
1251136835664118

 Request

e-skin mounting bracket
e-skin SK40 mounting bracket drawing

Shop interior separation

The interior separation system for the igus® e-skin consists of individual separators and shelves, which can be inserted in the e-skin in a variety of ways and attached to the ridges.




Part No.

SK40.1.01 - Separator, slotted, unassembled Request
SK40.1.1.01 - Separator, slotted, assembled Request
110.80.1 - Full-width shelf, unassembled Request
111.80.1 - Full-width shelf, assembled Request



Separator for the e-skin

More information

e-skin flat

Flat cable guidance system: e-skin® flat

  • Space requirement: from 80mm
  • Bend radius: from 40mm
  • Travel: depends on the guided cables

Browse e-skin flat

e-skin soft

e-skin® soft corrugated tube

  • Space requirement: < 200mm
  • Bend radius: 55mm
  • Travel, unsupported: 0.7m

Browse e-skin soft

Additional cleanroom products

Further cleanroom products

  • Cleanroom ISO class 1
  • Space-saving
  • Low vibration
